What's New for the Chandra Source Catalog?
CSCview access to CSC 2.0
Source properties - such as fluxes, variability measurements, and spectral fit results - and data products - event files, images, spectra - from CSC 2.0 are being made available to the community as they are processed. Data access is via CSCview or ADQL, and the current processing-status page provides an overview of the available data.
While all sources have undergone standard quality assurance evaluations, some may be deleted or have their properties revised as a result of further quality-assurance analyses step prior to the official CSC 2.0 release.
CSC release 2.0 pre-release (pre1)
The pre-release of the Chandra Source Catalog 2.0 is now available. Please see the caveats for this release before use. It adds source designations (name, position and error, and an estimate of the average flux) to the pd2 detections list.
CSC release 2.0 preliminary production release (pd2)
The latest release of the preliminary-detections list of the Chandra Source Catalog 2.0 is now available. Please see the caveats for this release before use. It supercedes the pd1 release from March 2017.
CSC release 2.0 preliminary production release (pd1)
The initial release of the preliminary-detections list of the Chandra Source Catalog 2.0 is now available. Please see the caveats for this release before use. It supercedes the pd0 release from August 2015.
CSC release 2.0 preliminary data release (pd0)
The first preliminary detections list from release 2.0 of the catalog has been released to the community.
CSC release 1.3 internal updates
Users will now get a pop-up box alerting them if a newer version of the application is available.
Updating will be optional as long as the current version of the application is compatible with the CSC servers. If not users will see an alert like this:
that will require them to download the latest version. Users will also be alerted when the CSC servers are down for maintenance
or if the application detects any connectivity problems.
In addition, the VOtable output format has also been updated to correct problems in the
schema location attribute that could have caused problems for applications
trying to make use of those attributes. Finally, the "G" format
has been replaced with "E" as per the
VOTable v1.2 recommendation
CSC release 1.2 compatibility updates
The CSCView Java applet is incompatible with Java version 7. This release provides a stand alone Java .jar file that users can now download that can be run with either Java 6 or Java 7. There is also a new Mac .dmg file that can be installed as a stand alone application.
There were also two other bug fixes: the unit string returned for the flux columns incorrectly identified the units as erg/s*cm^2 and photons/s*cm^2 when they are actually in units of erg/s/cm^2 and photons/s/cm^2. The values are correct; simply the unit string was in error. There was also a bug fix that prevented queries that contained date/time values, ie gti_obs, from working properly.
CSC release 1.1 interface updates
CSCview now features a crossmatch function which allows you to locate CSC counterparts to sources of interest by uploading, transmitting, or directly entering a table of source positions (and optionally, position errors) to the GUI. To use the CSCview crossmatch, launch CSCview from the CSC homepage and select "Crossmatch" in the lower-right corner of the Query tab. For help using the crossmatch, refer to the CSCview help page.
CSC release 1.1
CSC release 1.1 became available on 11 August 2010. This version extends release 1.0.1 to include point and compact source data extracted from qualifying HRC imaging observations from the start of the mission through December 2009, in addition to recently released 'catch-up' ACIS observations. A new version of CSCview also became available with this release.
ACIS and HRC data
CSC release 1.1 includes 655 new ACIS imaging ObsIDs (-120 degree data only) and 625 HRC-I ObsIDs. There are 106,586 distinct (i.e., "master") sources currently in the catalog, up from 94,676 in release 1.0.1. Of these, 104,628 were detected only in ACIS observations; 1,034 were detected only in HRC-I observations; and 924 were detected in observations made with both detectors.
The "source observation" properties derived from 158,071 source detections in 5,110 Chandra ObsIDS - 152,296 ACIS sources and 5,775 HRC sources - contributed to the "master source" properties contained in the catalog.
- CSCview, the CSC data access GUI application, now supports a SAMP connection via the Send toolbar option. This feature allows you to transmit tables of source data and data files returned by a CSCview query to compatible applications such as SAOImage DS9 and TOPCAT, as demonstrated in the CSC threads.
- It is now possible to save a table of CSCview query results in both Tab Separated Values (TSV) and VOTable TABLEDATA format, replacing the Relational Database (RDB) format output by CSCview in release 1.0.1. See example save files cscresults.tsv and cscresults.vot.
- A new metadata display at the bottom of the CSCview Query and Results tabs lists the name, data type, units, and description of selected source properties, and the product type, product specifier, format, and description of selected data products.
- The CSCview Results tab now has a Source Preview feature which allows you to view and save images of sources in selected rows of a query results table. Source region images available in Source Preview include a tricolor soft-medium-broad (red-green-blue) events image, a single-color events image in any of the selected CSC energy bands (ultrasoft, soft, medium, hard, broad, wide), and a PSF image in any CSC energy band. The full-field broad-band events image is available at different blocking factors; they are 1, 2, and 4 for ACIS data, and 2, 5, and 12 for HRC data.
