Cycle 15 PIMMS Effective Areas

Return to: Proposal Planning Index

Released as of 13 DEC 2012

---

The PIMMS Effective Areas for Cycle 15 include upgrades for the HRC-S QE, the HETG GREFF first orders, and the LETG GREFF higher orders. As is always the case, the time-delay factor for the ACIS contaminant build-up has been updated for cy15.

The model OBS_IDs and the ARF-building scripts have now been standardized for Chandra PIMMS calculations. Hence the procedures are the same as with cy14.

---

The Cycle 15 PIMMS Effective Area Public Information describes how the effective area files were generated, including the new HETG and LETG GREFFs and the new HRC-S QE file.

Effective area plots are provided for the following detector configurations:

• ACIS-I
• ACIS-S
• HRC-I
• HRC-S
• HETG/ACIS-I
• HETG/ACIS-S
• LETG/ACIS-I
• LETG/ACIS-S
• LETG/HRC-I
• LETG/HRC-S

---

Left Column: Linear Scale	Center Column: Log Scale	Right Column: Difference Plot
ACIS-I Aimpoint Effective Areas The black traces indicate ACIS effective areas uncorrected for OBF contamination.
ACIS-S Aimpoint Effective Areas The black traces indicate ACIS effective areas uncorrected for OBF contamination.
HRC-I Aimpoint Effective Areas
HRC-S Aimpoint Effective Areas
HETG/ACIS-I Effective Areas
HETG/ACIS-S Effective Areas
LETG/ACIS-I Effective Areas
LETG/ACIS-S Effective Areas
LETG/HRC-I Effective Areas
LETG/HRC-S Effective Areas
